DB DRIVE 300 X 4 + 1000 X 1 @ 1 OHM FULL RANGE AMPLIFIER (WDXPRO2500.5)

4 x 100 Watts @ 4 ohms
4 x 200 Watts @ 2 ohms
4 x 300 Watts @ 1 ohm
(5th Ch) 1 x 1000 Watts @ 1 ohm
Working Voltage: 12-15 Volts
Frequency Response: 15 Hz - 20k Hz
Signal to Noise Ratio: <96dB
ACT - Variable Crossover HP/BP/LP
Damping Factor: ≥200
Low Level Input: 6V - 0.2mV
Ch 1/2 High Pass Filter Variable: 15 Hz - 2k Hz
Ch 1/2 Low Pass Filter Variable: 50 Hz - 2k Hz
Ch 3/4 High Pass Filter Variable: 15 Hz - 2k Hz
Ch 3/4 Low Pass Filter Variable: 50 Hz - 2k Hz
Minimum working Impedance: 1 Ohm

ATC - Audiophile RCA Connectors
ACT - Adaptive Crossover Technology
High efficiency Class Full Range Class D Technology
Direct Connect Speaker Terminals
0 Gauge Power Wire Inputs
APC - Audio Protection Circuit
SESI - Signal Evaluation Status Indicator
Bass Remote with voltage, temperature and signal status indicator
CHM - Collective Heat Management

Achieve superior audio performance with the DB Drive WDX PRO2500.5, a 5-channel Class D amplifier built for high output and crystal-clear sound. Effortlessly power your full 4-channel stereo system alongside an additional subwoofer. Key Features: Adaptive Crossover: Optimizes performance for tweeters, mids, and subwoofers. CHM: Ensures consistent power and prevents overheating. SESI Circuit: Monitors in real time to protect against overdriving. Large-Gauge Terminals: Supports 4-gauge wiring for maximum efficiency. With 4 x 200 Watts and 1 x 1000 Watts at 1Ω, the WDX PRO2500.5 elevates your car audio system, delivering powerful, dynamic sound.
