Details
VFL REBEL-5000.1 is a 1-channel Class D monoblock car audio amplifier.
RMS power at 4 ohms is 1600W x 1.
RMS power at 2 ohms is 3400W x 1.
RMS power at 1 ohm is 5000W x 1.
Minimum impedance is 1 ohm.
Number of channels is 1.
Amplifier class is Class D.
Amplifier type is digital power amplifier.
Bass boost range is 0 – 12dB.
Bass boost frequency is 30 – 70Hz.
Low pass filter range is 60Hz – 20KHz.
High pass filter range is 10Hz – 1KHz.
Frequency response is 10Hz – 20KHz.
Signal-to-noise ratio is less than 92dB.
THD is less than 0.4%.
Input sensitivity is 0.4 – 4V.
Fuse rating is 450A.
PCB construction is 4-layer.
Protection is 4-way.
LCD remote control with real-time voltage and clipping indicators is included.
Length is 7.05 inches.
Width is 8.66 inches.
Height is 2.24 inches.
