XPERT EUPHORIA 6.5" 400 WATT NEODYMIUM CARBON FIBER MIDRANGE (EXM6N-CFV2)

6.5” NEO Carbon Fiber Midrange speaker
Manufacturer: DB Drive
Model: EXM6N-CFV2
2.0” (51 mm) Voice Coil
Neodymium M-Ring Magnet Assembly
Optimized for High Output SQ Sound Systems
Weather-Resistant Carbon Fiber Cone with Cloth Surround
Custom Die-Cast Aluminum Basket with Radial Venting
Power Handling: 200 Watts
Dynamic Wattage (Peak): 400 Watts
Impedance: 3 Ω
Sensitivity: 98.7 dB (1 W/1 m)
Resonant Frequency (fs): 82.4 Hz
D.C. Voice Coil Resistance (Re): 3 Ω
Mechanical Quality Factor (Qms): 3.38
Electrical Quality Factor (Qes): 0.49
Total Quality Factor (Qts): 0.42
Compliance Equivalent Volume (Vas): 5.9 L
Mechanical Compliance (Cms): 0.24 mm/N
Overall Diameter: 6.52” (165.50 mm)
Cutout Diameter: 5.49” (139.50 mm)
Mounting Depth: 2.72” (69 mm)
